356nm Conveyor Belt Glue / Ink UV Conveyor

UV light curing machine, the light source can use a variety of mercury lamps, advanced design

concepts, good production technology, the operating temperature of the overall equipment is low,

and the drying and curing speed is fast.
Dimensions
1. Length 13000*H2200*W 3500mm
2. Conveying width 3000mm, entrance height: 400mm (adjustable downwards)

3. The length of the feeding zone is 2000mm, the length of the light solid zone is 2500mm, and the

length of the receiving zone is 4500mm.
Shell material
It is made by bending and welding 1.5mm thick Q235 cold-rolled steel plate (the best comprehensive

performance of strength, plasticity and welding).

Surface treatment
1. Surface grinding, polishing and phosphating (which can increase the corrosion resistance of metal

and the adhesion of paint)
2. High temperature plastic spraying (large corrugated type) to prevent rust and corrosion. The color

is "computer gray"

UV radiation protection method
The feed inlet adopts upper and lower pneumatic doors to prevent ultraviolet radiation. When the

product enters, the cylinder door is opened automatically or manually, and the door is automatically

closed when the product enters the cylinder door. Other light leakage areas are sealed with Ams tape,

and the inlet and outlet are equipped with anti-ultraviolet Teflon curtains, which can effectively shading

and strengthen the sealing effect.

UV lamp adjustment mechanism The lampshade adopts a rotary adjustment method, which can freely

adjust the position, height and angle of the lamp tube.
The height of the lamp holder is adjusted as a whole by the handle of the stove top, and the height can

be adjusted from 10-150mm.
The conveyor belt is conveyed by high temperature resistant Teflon.
